PipeWire Quantum vs XRun Threshold: The 2026 Dataset (Published Methods, Published Raw Numbers)

Most PipeWire tuning advice is anecdotal. Someone found a quantum that works on their machine and posted it as universal truth. The problem is that XRun behavior depends on the interaction between CPU, USB controller, audio interface, kernel configuration, and workload - and nobody publishes the data to prove it.

This article publishes the data. Five hardware configurations, five quantum values each, 60-minute test windows, documented load generation, and raw XRun counts. Use it to calibrate expectations for your own setup. The methods are published so you can extend the dataset with your own hardware.

Why this dataset exists

The quantum selection guide describes how to find your XRun threshold by testing. That guide tells you the method. This article shows the results of applying that method systematically across five different systems. The RTL leaderboard measures latency under clean conditions. This dataset measures where things break under sustained load.

The two datasets are complementary. The leaderboard tells you how fast an interface can be. This dataset tells you how low you can push the quantum before your specific combination of hardware falls over.

Test methodology

Load generation

The synthetic load uses jalv (the LV2 host) running chains of Calf plugins to create a realistic CPU-intensive audio workload. The specific plugin chain per voice:

# Find the Calf plugin URIs on your system
lv2ls | grep calf

# Single voice: EQ -> Compressor -> Reverb
# Use the URIs from lv2ls output - these are LV2 identifiers, not URLs
EQ_URI=$(lv2ls | grep -i "calf.*equalizer8")
COMP_URI=$(lv2ls | grep -i "calf.*compressor")
REV_URI=$(lv2ls | grep -i "calf.*reverb")

jalv $EQ_URI &
jalv $COMP_URI &
jalv $REV_URI &

The input for each chain is pw-cat feeding a looped 60-second wav file at 48 kHz stereo:

pw-cat --playback --target 0 test-signal.wav --format s16 --rate 48000 --channels 2 &

Each test run uses 12 voices (36 plugin instances total). This approximates a moderate-to-heavy DAW session with EQ, dynamics, and spatial processing on every track. The total DSP load at quantum 128 on a modern CPU is roughly 35-50% of a single core, which is high enough to stress the scheduling without being pathological.

XRun detection

XRuns are counted using pw-top output captured to a log file:

# Log pw-top output every second for the test duration
while true; do
    pw-top -b -n 1 >> /tmp/pw-xrun-log-$(date +%s).txt
    sleep 1
done &

The ERR column in pw-top provides cumulative XRun counts per node. At the end of each 60-minute window, the total XRun count across all nodes is summed. The W/Q peak (wait time as fraction of quantum period) is also recorded - this is the closest the system came to the deadline without necessarily producing an XRun.

Test window

Each quantum value is tested for 60 continuous minutes under load. Between tests, PipeWire is restarted and the system idles for 5 minutes to reach thermal equilibrium. The quantum is set with:

pw-metadata -n settings 0 clock.force-quantum <value>

All tests run at 48 kHz sample rate.

What is controlled

• CPU governor: performance (no frequency scaling)
• USB autosuspend: disabled
• Wi-Fi: disabled
• Display compositor: running (Wayland, default GNOME on Ubuntu Studio)
• Browser: closed
• No background updates or cron jobs during test windows

Hardware configurations

Config	CPU	Interface	USB Controller	Kernel	RT Scheduling
A	Ryzen 7 7800X3D	RME Babyface Pro FS	AMD XHCI	6.12.8 PREEMPT_DYNAMIC	rlimits SCHED_FIFO 78
B	Ryzen 7 7800X3D	Focusrite Scarlett 4i4 4th Gen	AMD XHCI	6.12.8 PREEMPT_DYNAMIC	rlimits SCHED_FIFO 78
C	Intel i5-1340P (laptop)	MOTU M4	Intel XHCI	6.12.8 PREEMPT_DYNAMIC	rtkit (portal)
D	Intel i5-1340P (laptop)	Behringer UMC404HD	Intel XHCI	6.12.8 PREEMPT_DYNAMIC	rtkit (portal)
E	Ryzen 5 5600G	Steinberg UR22C	AMD XHCI	6.12.6 PREEMPT_RT	rlimits SCHED_FIFO 78

Configurations A and B share the same host - only the interface changes. Configurations C and D share the laptop - same principle. Configuration E uses a PREEMPT_RT kernel to test whether full preemption changes the XRun picture.

PipeWire version is 1.6.0 on all configurations. WirePlumber 0.5.6. Ubuntu Studio 26.04 LTS base on all except Config E which runs Fedora 42 with the Jam spin.

The dataset

Configuration A: Ryzen 7 7800X3D + RME Babyface Pro FS

Quantum	XRuns (60 min)	First XRun (min:sec)	Peak W/Q	Mean W/Q
32	847	00:01	1.00	0.94
64	3	22:14	0.97	0.61
128	0	-	0.52	0.34
256	0	-	0.31	0.19
512	0	-	0.18	0.10

Configuration B: Ryzen 7 7800X3D + Focusrite Scarlett 4i4

Quantum	XRuns (60 min)	First XRun (min:sec)	Peak W/Q	Mean W/Q
32	2341	00:00	1.00	0.98
64	47	01:12	1.00	0.78
128	0	-	0.68	0.42
256	0	-	0.38	0.23
512	0	-	0.21	0.12

Configuration C: i5-1340P laptop + MOTU M4

Quantum	XRuns (60 min)	First XRun (min:sec)	Peak W/Q	Mean W/Q
32	5102	00:00	1.00	0.99
64	284	00:08	1.00	0.89
128	8	07:33	0.98	0.58
256	0	-	0.47	0.31
512	0	-	0.26	0.16

Configuration D: i5-1340P laptop + Behringer UMC404HD

Quantum	XRuns (60 min)	First XRun (min:sec)	Peak W/Q	Mean W/Q
32	6830	00:00	1.00	0.99
64	512	00:03	1.00	0.92
128	31	02:45	1.00	0.71
256	2	38:11	0.93	0.36
512	0	-	0.29	0.18

Configuration E: Ryzen 5 5600G + Steinberg UR22C (PREEMPT_RT kernel)

Quantum	XRuns (60 min)	First XRun (min:sec)	Peak W/Q	Mean W/Q
32	192	00:02	1.00	0.96
64	0	-	0.82	0.55
128	0	-	0.44	0.29
256	0	-	0.25	0.15
512	0	-	0.14	0.08

Analysis of patterns

Interface firmware quality dominates at low quantum

Compare Configs A and B - same CPU, same USB controller, same kernel, same scheduling. The only difference is the audio interface. At quantum 64, the RME produced 3 XRuns in 60 minutes. The Focusrite produced 47. At quantum 128, both are clean, but the Focusrite's peak W/Q (0.68) is significantly higher than the RME's (0.52).

The same pattern appears in Configs C vs D on the laptop. The MOTU M4 at quantum 128 produced 8 XRuns. The Behringer on the same machine produced 31. The interface's USB firmware - how it handles isochronous transfers, feedback, and buffer management - is the dominant variable at aggressive quantum values.

CPU and scheduling matter more at moderate quantum

Config D (laptop + Behringer) still had 2 XRuns at quantum 256 over 60 minutes. Config B (desktop + Focusrite) had zero at quantum 128. The desktop's faster single-thread performance and direct rlimits RT scheduling (vs the laptop's rtkit) provide the headroom that eliminates marginal XRuns.

The difference between rtkit and direct rlimits is covered in the RT scheduling guide. In this dataset, the effect shows up as higher peak W/Q values on the laptop configs even at quantum values where both are XRun-free. The laptop runs closer to the deadline more often.

PREEMPT_RT makes a measurable difference

Config E (PREEMPT_RT kernel) achieved zero XRuns at quantum 64 with a mid-range CPU and a mid-tier interface. Config B (PREEMPT_DYNAMIC) with a faster CPU and the same class of interface had 47 XRuns at quantum 64. Full kernel preemption reduces worst-case scheduling latency enough to clear the deadline at quantum 64 for this workload.

The PREEMPT_RT analysis in the kernel tuning guide covers the theoretical basis. This dataset quantifies the practical benefit: one quantum step lower without XRuns.

The W/Q safety margin

Peak W/Q is the most useful predictor of trouble. Any configuration with peak W/Q above 0.85 at a given quantum is at risk of intermittent XRuns even if the 60-minute test came back clean. System activity you cannot control - a timer interrupt, a USB hub event, a filesystem journal flush - will occasionally push processing past the deadline.

The practical safe threshold based on this data is peak W/Q below 0.75. Configurations that hit that target at a given quantum were universally XRun-free across all test runs, including re-tests not shown here.

What the data says about safe quantum choices

Based on these five configurations and this workload (12 voices, 36 plugins):

System class	Interface quality	Kernel	Safe quantum	Conservative quantum
Desktop (modern CPU)	Premium (RME)	PREEMPT_DYNAMIC	64	128
Desktop (modern CPU)	Mid-range (Focusrite, Steinberg)	PREEMPT_DYNAMIC	128	256
Desktop (modern CPU)	Mid-range	PREEMPT_RT	64	128
Laptop (mobile CPU)	Premium (MOTU)	PREEMPT_DYNAMIC	256	256
Laptop (mobile CPU)	Budget (Behringer)	PREEMPT_DYNAMIC	512	512

"Safe" means zero XRuns in the 60-minute test with peak W/Q below 0.75. "Conservative" adds one quantum step of margin.

How to use this data for your own hardware

1. Identify which configuration most closely matches your system (CPU class, interface tier, kernel type, RT scheduling method).
2. Use the corresponding safe quantum as a starting point.
3. Run the quantum selection test on your own system to validate.
4. Your workload will differ - heavier plugin loads need higher quantum, lighter loads may tolerate lower.

To replicate this exact test:

# Install Calf plugins and jalv
sudo apt install calf-plugins jalv

# Generate a test signal (60-second stereo sine sweep)
sox -n -r 48000 -c 2 test-signal.wav synth 60 sine 100-10000

# Start 12 voices (example for 3 instances, repeat 4x)
for i in $(seq 1 12); do
    jalv $EQ_URI &
    jalv $COMP_URI &
    jalv $REV_URI &
done

# Start playback sources
for i in $(seq 1 12); do
    pw-cat --playback --target 0 test-signal.wav --format s16 --rate 48000 --channels 2 &
done

# Set quantum and begin monitoring
pw-metadata -n settings 0 clock.force-quantum 128
pw-top

Monitor pw-top for 60 minutes. Record ERR counts and peak W/Q. Then change quantum and repeat.

Limitations and caveats

Synthetic load vs real DAW workload. Plugin chains in a DAW interact differently than isolated jalv instances. DAWs add their own processing overhead, UI rendering, and disk I/O. The synthetic load is repeatable and comparable, but your actual DAW may behave differently. Use these numbers as a calibration baseline, not as a guarantee.

12 voices is a specific load level. If your projects routinely use 30+ tracks with heavy plugins, your XRun threshold will be higher (needing larger quantum). If you run 4-track acoustic recordings, your threshold will be lower.

Thermal conditions matter on laptops. Configurations C and D were tested with the laptop on a flat desk in a 22C room. Thermal throttling on a hot laptop can shift the XRun threshold by one or two quantum steps.

USB controller variation. Different USB controllers on the same CPU architecture can produce different results. This is a known variable that we could not isolate in this dataset.

PipeWire version. The scheduling improvements in PipeWire 1.6.0 may differ from earlier or later versions. Pin your PipeWire version if you want comparable results.

Further latency data and interactive graphs are available in the latency graph collection and the benchmark archive.

FAQ

Can I submit my own data to extend this dataset? Follow the methodology described here and compare your results against the configuration that most closely matches your hardware. If your methodology is consistent, the numbers should be comparable.

Why 60-minute test windows? Shorter tests miss intermittent XRuns caused by periodic system activity (cron jobs, journal flushes, NTP adjustments). 60 minutes captures most periodic events. Longer would be better but impractical for systematic testing.

Why not test quantum 16? No configuration in this dataset was stable at quantum 16. It produced continuous XRuns on every system, even with zero audio load. PipeWire's own graph processing overhead exceeds the 0.33 ms deadline at quantum 16 on all tested hardware.

How does sample rate affect these numbers? At 96 kHz, quantum 128 gives 1.33 ms per period - equivalent to quantum 64 at 48 kHz. Expect XRun behavior at 96 kHz / quantum 128 to resemble the quantum 64 rows in these tables.

Conclusion

The data confirms what experienced Linux audio users already suspected: interface quality and kernel preemption are the two biggest variables for XRun-free operation at low quantum values. A premium interface on PREEMPT_RT can hold quantum 64 under moderate load. A budget interface on a laptop needs quantum 512 to be safe. The numbers are here. Use them as a starting point, verify on your own hardware, and stop guessing.
